Crane Cables for Seaports, Mining and Material Handling

Crane and Material Handling, Reeling and Festoon Cables

Crane and Material Handling, Reeling and Festoon Cables

Draka Cable

Prysmian Group

FLAT-FLEX® Festooning Cable

Festooning Cable / 105°C to -40°C / 16 to 2/0 AWG / PVC Jacket /UL & CSA Listed / 600V

Applications

FLAT-FLEX® Festooning Cable is primarily designed for use with festoon systems for the conveyance of electrical power and control to cranes, hoists, or any other equipment which travels with a lateral traversing motion. FLAT-FLEX® cables can also be used where space is at a premium, since it can be stacked; or where extreme flexing is a requirement, recommended bend radius of three to five times cable diameter. FLAT-FLEX® cables are suitable for either indoor or outdoor applications operating at -40°C to 105°C. However, they are not recommended for severe flexing or impact at temperatures below -10°C. For severe flexing applications below -10°C, specify FLAT-FLEX® Neoprene Festoon Cables.

Additional Product Information

FLAT-FLEX® Festooning Cable - Prysmian Group

ALL-TEMP (K) Flat Industrite NEOPRENE-Power & Control

Festooning Cable / -40° C TO 90° C / 16 to 4/0 AWG / Neoprene jacket / Control (600V) & Power (2000V)

Applications

Festoon Application

ALL-TEMP(K) Flat Neoprene Festooning Cable is primarily designed for use with festoon systems for the conveyance of electrical power and control to cranes, hoists, or any other equipment which travels with a lateral traversing motion. ALL-TEMP(K) Flat cables can also be used where space is at a premium, since it can be stacked; or where extreme flexing is a requirement, recommended bend radius of three to five times cable diameter. ALL-TEMP(K) Flat cables are suitable for either indoor or outdoor applications operating at -40°C to 90°C.

ALL-TEMP(K) Flat Neoprene Festooning Cable -Prysmian Group

BOSTREEL Power Reeling Cable

90°C to -40°C /6AWG-500KCMIL/ Thermoset Jacket / UL Listed MV-90 CSA Listed / 5,8 and 15KV

Applications

BOSTREEL ALL-TEMP Portable Power Reeling Cable is designed and manufactured for use in medium voltage reeling applications on container handling cranes, log handling cranes, stacker reclaimers, ship loaders and unloaders, and other similar material handling applications where flame, abrasion, chemicals, moisture, impact, tearing and temperature extremes are considerations.

BOSTREEL ALL-TEMP power reeling cables are manufactured to be resistant to the unique tension and torsional stresses common to high mounted cable reels and high travel speeds without compromising safe operation.

BOSTREEL Power Reeling Cable - Prysmian Group

INDUSTRITE C-FLEX Power and Control

For shipyard crane and festoon systems / 90° C to -40° C / 600V

Applications

INDUSTRITE C-FLEX cables are designed and manufactured for use in festoon systems functioning on gantry cranes or other material handling equipment.

C-FLEX cables are typically used in applications requiring frequent flexing and mechanical stress. C-FLEX is recommended for festoon systems operating at travel speeds up to 200 meters per minute. Consult Draka for speeds greater than 200 m/min based on system design.

Additional Product Information

INDUSTRITE C-FLEX cables  - Prysmian Group

Crane Spreader Reeling Cable

Rated for continuous operation at 75° C to -40° C in wet or dry locations

Applications

Crane Spreader Reeling Cable is specifically designed and manufactured to withstand abusive environments, high hoist and trolley speeds and extreme mechanical stresses predominant on vertical reeling systems found in new generation ship to shore container cranes.

Additional Product Information

Crane Spreader Reeling Cable - Prysmian Group

Crane Basket Spreader Cable

For high-speed container cranes / 24 to 48 conductors / 160 m/min travel speed rubber jacket / 600V

Applications

All temp basket spreader cable is specifically designed for use on the latest generations of high-speed container cranes with gravity-fed collector baskets. They combine the features of superior flexibility with additional ballast needed to operate at speeds of up to 160 meters/ min (8.75 ft/sec).

Features such as extra stranded conductors and non-wicking, non-hygroscopic llers and synthetic rubber insulation produce a cable that is both durable and flexible. Group bundling around an aramid central strength member reduces the chance for knotting or corkscrewing. A specially formulated ‘heavy’ synthetic rubber jacket adds the weight needed to perform despite poor basket design or high winds. The operating temperature range is -40° to +90°C.

This cable can be produced with shielded copper or ber optic data communications components. This cable is RoHS (Reduction Of Hazardous Substances) compliant which eliminates the need for special disposal methods.

NOTE: This cable is not designed for applications using sheaves or guide rollers.

Crane Basket Spreader Cable - Prysmian Group

BOSTGARD Soaking Pit Cable

Soaking Pit Cable / 200°C / 14 to 2/0 AWG / Stainless Steel Armor / 600V

Applications

BOSTGARD Soaking Pit Cable is designed and manufactured to provide long life under extreme heat and severe flexing conditions.

Applications include use on ingot transfer cars, scrap charging machines, soaking pit cranes, mud guns, ladle transfer cars, and in severe environmental conditions where extreme heat and abrasion are factors. BOSTGARD cables are well suited for flexing applications such as festoon systems and cable reels.

Additional Product Information

BOSTGARD Soaking Pit Cable - Prysmian Group

PENDFLEX-PVC Pendant Control Cable

Type MTW pendant control cable / 90° C / 16 AWG / PVC jacket / 600V

Applications

PENDFLEX Pendant Control Cable is designed to provide maximum Flex-Life under the most demanding continuous flexing conditions where flame, chemicals, moisture, and temperature extremes are considerations.

PENDFLEX applications include portable control, festoon systems, pendant stations, power tracks, cranes and hoists, power carriage systems and other flexing applications.

Additional Product Information

PENDFLEX-PVC Pendant Control Cable  -  Prysmian Group

FIBER-FLEX®

Optical fiber festooning cable / 90c to -40c/ 62.5 multimode fiber fluoropolymer & neoprene jackets.

Fluoropolymer & neoprene jackets.

FIBER-FLEX® Festooning Cable is designed primarily for installation on festoon systems for the transmission of optical data. In addition to festoon systems. FIBER-FLEX® is also suitable for installation in cable track.

FIBER-FLEX® is suitable for use indoor or outdoor at temperatures ranging from 90°C to -40°C on cranes, hoists, or any equipment which travels with a lateral traversing motion.

FIBER-FLEX® Festooning Cable - Prysmian Group

ALL-TEMP INDUSTRITE® Magnet Crane Cable

Type W Magnet Crane Cable/ 105°C To-50°C/ 8 to 2/0 AWG / Thermoset Jacket /UL Type W CSA TYPE W FT1 / 2000V

Applications

ALL-TEMP INDUSTRITE® Magnet Crane Cable is designed and manufactured to withstand the abusive environment predominant in magnet crane areas of operation. ALL-TEMP INDUSTRITE® resists cut through, puncture, tearing, abrasion and impact better than standard Type W because of the rugged design and material selection.

ALL-TEMP INDUSTRITE® Magnet Crane Cables are ideal for use in scrap yards, foundries, and other installations where there is a severe risk of metal cut through.

Additional Product Information

ALL-TEMP INDUSTRITE® Magnet Crane Cable

ALL-TEMP INDUSTRITE® Shovel and Dragline Cable

Type SHD-GC / 90° C TO -40° C / 14 to 2/0 AWG / thermoset jacket / 2000 volts

Applications

ALL-TEMP INDUSTRITE® SHD-GC cable is designed and manufactured for use as a heavy-duty trailing cable on mining equipment where flame, abrasion, chemicals, moisture, impact, tearing and temperature extremes are part of the work environment.These cables are manufactured to be resistant to harsh environments without compromising safety.

ALL-TEMP INDUSTRITE® SHD-GC cable
